GE 20 ES Spherical Plain Bearing, ID-20mm, OD-35mm With Dustproof Sealing Cover

  • 1
  • 2

Brand Name : QRL

Model Number : GE 20 ES

Certification : ISO9001/2000

Place of Origin : CHINA

MOQ : 5

Payment Terms : D/P, T/T, Western Union, L/C

Supply Ability : 6500pcs

Delivery Time : 1-15days

Packaging Details : Carton/woven bag

Type : Spherical Plain Bearing

Oe no. : GE 20 ES

Size : 20x35x16 MM

Product name : industrial machinery

Weight : 0.4 kg/pcs

Contact Now

GE 20 ES Spherical Plain Bearing, ID-20mm, OD-35mm With dustproof sealing cover

Spherical Plain Bearing Specification

d 20 mm Bore diameter bearing
D 35 mm Outside diameter bearing
B 16 mm Width Inner ring
Cr 30.500 N Basic dynamic load rating, radial
C0r 117.000 N Basic static load rating, radial
M 0,4kg Weight

Spherical Plain Bearing Description

Radial spherical plain bearings have an inner ring with a sphered convex outside surface and an outer ring with a correspondingly sphered but concave inside surface.

Spherical Plain Bearing Number

Bearing Type Dimensions/mm α/(°)≈
GE…E型 GE…ES GE…DS GE…C GE…ES-2RS d D B C d1≈ dk① rsmin r1smin Other GE…ES-2RS型
GE4E － － GE4C － 4 12 5 3 6 8 0.3 0.3 16 －
GE5E － GE5DS GE5C － 5 14 6 4 8 10 0.3 0.3 13 －
GE6E － GE6DS GE6C － 6 14 6 4 8 10 0.3 0.3 13 －
GE8E － GESDS GE8C － 8 16 8 5 10 13 0.3 0.3 15 －
GE10E － GE10DS GE10C － 10 19 9 6 13 16 0.3 0.3 12 －
GE12E － GE12DS GE12C － 12 22 10 7 15 18 0.3 0.3 10 －
－ GE15ES GE15DS GE15C GE15ES-2RS 15 26 12 9 18 22 0.3 0.3 8 5
－ GE17ES GE17DS GE17C GE17ES-2RS 17 30 14 10 20 25 0.3 0.3 10 7
－ GE20ES GE20DS GE20C GE20ES-2RS 20 35 16 12 24 29 0.3 0.3 9 6
－ GE25ES GE25DS GE25C GE25ES-2RS 25 42 20 16 29 35 0.6 0.6 7 4
－ GE30ES GE30DS GE30C GE30ES-2RS 30 47 22 18 34 40 0.6 0.6 6 4
－ GE35ES GE35DS － GE35ES-2RS 35 55 25 20 39 47 0.6 1 6 4
－ GE40ES GE40DS － GE40ES-2RS 40 62 28 22 45 53 0.6 1 7 4
－ GE45ES GE45DS － GE45ES-2RS 45 68 32 25 50 60 0.6 1 7 4
－ GE50ES GE50DS － GE50ES-2RS 50 75 35 28 55 66 0.6 1 6 4
－ GE55ES GE55DS － GE55ES-2RS 55 85 40 32 62 74 0.6 1 7 －
－ GE60ES GE60DS － GE60ES-2RS 60 90 44 36 66 80 1 1 6 3
－ GE70ES GE70DS － GE70ES-2RS 70 105 49 40 77 92 1 1 6 4
－ GE80ES GE80DS － GE80ES-2RS 80 120 55 45 88 105 1 1 6 4
－ GE90ES GE90DS － GE90ES-2RS 90 130 60 50 98 115 1 1 5 3
－ GE100ES GE100DS － GE100ES-2RS 100 150 70 55 109 130 1 1 7 5
－ GE110ES GE110DS － GE110ES-2RS 110 160 70 55 120 140 1 1 6 4
－ GE120ES GE120DS － GE120ES-2RS 120 180 85 70 130 160 1 1 6 4
－ GE140ES GE140DS － GE140ES-2RS 140 210 90 70 150 180 1 1 7 5
－ GE160ES GE160DS － GE160ES-2RS 160 230 105 80 170 200 1 1 8 6
－ GE180ES GE180DS － GE180ES-2RS 180 260 105 80 192 225 1.1 1.1 6 5
－ GE200ES GE200DS － GE200ES-2RS 200 290 130 100 212 250 1.1 1.1 7 6



Spherical Plain Bearing Delivery

According to different applications, bearings without inner ring or needle roller and cage components can be selected. At this time, the journal surface and shell hole surface matching the bearing are directly used as the inner and outer rolling surfaces of the bearing to ensure the load capacity and running performance Same as the bearing with ring, the hardness, machining accuracy and surface quality of the raceway surface of the shaft or housing hole should be similar to the raceway of the bearing ring. This kind of bearing can only bear radial load.
